The Hyster D138 series forklifts, including models N40FR, N45FR, and N50FA, are electric material handling vehicles engineered for reliability and efficiency. These forklifts feature advanced components such as the Vista Mast, Reach Carriage, and sophisticated motor controllers including EV-100, Curtis Transistor, and EV-100/200LX variants. Designed for demanding industrial environments, the D138 series embodies Hyster's commitment to robust construction and operational excellence, ensuring consistent performance for a wide range of material handling tasks.
This comprehensive Service Repair Workshop Manual provides detailed information essential for the maintenance and repair of your Hyster D138 forklift. It covers critical systems including the drive system, motor controllers, brake and steering systems, hydraulic system, electrical system, and battery system. Additionally, the manual details periodic maintenance schedules, technical specifications, fastener information (INCH/SAE and METRIC), and includes diagrams for various models. This resource is designed to assist owners, mechanics, and technicians in understanding, servicing, and troubleshooting these forklifts to ensure optimal operation and longevity.
This is the complete factory service repair workshop manual for the Hyster D138 (N40FR, N45FR, N50FA) Forklift.This Service Manual has easy-to-read text sections with top quality diagrams and instructions.They are specifically written for the do-it-yourselfer as well as the experienced mechanic.With step by step instruction & highly detailed exploded pictures & diagrams to show you how to complete the required job correctly & efficiently Using. Hyster D138 (N40FR, N45FR, N50FA) Forklift Service Repair Workshop Manual covers every single detail on your machine.provides step-by-step instructions based on the complete disassembly of the machine.This repair manual is an inexpensive way to keep you vehicle working properly.
Models Covered:
Hyster D138 (N40FR) Forklift
Hyster D138 (N45FR) Forklift
Hyster D138 (N50FA) Forklift
Service Repair Manual Covers:
FRAME
DC MOTOR
MASTER DRIVE UNIT
STEERING CONTROL UNIT
STEERING SYSTEM
BRAKE SYSTEM
HYDRAULIC GEAR PUMPS
HYDRAULIC SYSTEM
EV-100 MOTOR CONTROLLER-DESCR / OPER
EV-100 MOTOR CONTROLLER-REPAIR
EV-100 MOTOR CONTROLLER-TROUBLESHOOTING
ELECTRICAL ADJUSTMENTS
CURTIS TRANSISTOR MOTOR CONTROLLER
EV-100/200LX MOTOR CONTROLLER and HANDSET
INDUSTRIAL BATTERY
BATTERY INDICATORS
LIFT CYLINDERS
VISTA UPRIGHT-DESCRIPTION
VISTA UPRIGHT-REPAIR
VISTA MAST-DESCRIPTION (N40-45FR, N50FA)
LIFT CYLINDERS (N40-45FR, N50FA)
VISTA MAST-REPAIR (N40-45FR, N50FA)
REACH CARRIAGES (N40-45ER)
REACH CARRIAGES (N30-40-45FR)
INCH (SAE) and METRIC FASTENERS
PERIODIC MAINTENANCE
DIAGRAMS (N40-50EA, N40-45ER)
CAPACITIES and SPECIFICATIONS
DIAGRAMS (N40-45FR, N50FA)
DIAGRAMS (N30FR)
And More......
============================================================
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
NO waiting,Instant Download.All pages are printable. Hyster D138 (N40FR, N45FR, N50FA) Forklift Service Repair Workshop Manual are saving you money on postage and packaging.It is great to have.
