This manual covers Zetor tractors, specifically models 4712, 4718, 5711, 5718, 5745, 5748, 6711, 6718, 6745, and 6748, likely produced from the late 1970s through the 1980s. These utility tractors are known for their robust construction, simplicity, and affordability, making them suitable for demanding agricultural and industrial applications. The 47xx and 57xx series likely share a common platform, with the '4' designation indicating four-wheel drive variants. Designed with a focus on reliability and ease of maintenance, these tractors offer straightforward mechanical systems and strong low-end torque for heavy load pulling.
This comprehensive workshop and service manual provides detailed information for owners, mechanics, and technicians. It covers a wide array of systems including the engine, drivetrain, braking system, steering, electrical equipment, suspension, chassis, body, hydraulics, and ancillaries. Procedures included range from routine maintenance and adjustments to troubleshooting, repair, and complete overhaul of major components. Technical specifications, assembly tool listings, and diagnostic guides are also provided, ensuring that users have the necessary resources to maintain and repair these Zetor tractors effectively.
FOUND IT CHEAPER ON TRADEBIT? LET US KNOW WE WILL REDUCE ;-)
ZETOR TRACTOR WORKSHOP MANUAL
FOR ZETOR MODELS:
4712
4718
5711
5718
5745
5748
6711
6718
6745
6748
SECTIONS INCLUDE:
1. General hints for removal & re-fit,
2. Specifications,
3. Hood,
4. Cooling System,
5. Fuel System,
6. Lubrication System,
7. Cylinder Head,
8. Valve Gear,
9. Crank Mechanism,
10. Twin-purpose Clutch,
11. Compressor,
12. Gearbox,
13. Torque Multiplier,
14. Synchro-mesh Coupling,
15. Main Transmission Housing,
16. Portals,
17. Hydraulic Brakes,
18. Hand Brake,
19. Front Axle,
20. Sprung Extensions,
21. Front Driving Axle (Z 5745, Z 5748),
22. Front Driving Axle (Z 6745, Z 6748).
23. Ball-type Steering Mechanism,
24, Electrical Equipment,
25. Steering Booster,
26. Steering Damper,
27. Suspension,
28. Belt-pulley,
29. Safety Cab,
30. Hot-air Heating,
31. Seat,
32. Pneumatic Brakes,
33. Tyres,
34. Hydraulic Lift Unit,
35. List of Shaft Seals & Bearings,
36. List of Assembly Tools.
