This manual covers the Yale F813 Series Diesel/LPG Forklift Trucks, including models GDP080VX through GDP120VX and GLP080VX through GLP120VX, as well as GP080VX through GP120VX. These robust forklifts are engineered for demanding industrial environments, offering reliable performance and efficient operation. With a focus on durability and functionality, the F813 Series is designed to meet the rigorous requirements of material handling tasks across various sectors.
This comprehensive service manual provides detailed instructions and high-quality illustrations for the operation and repair of your Yale forklift. It includes extensive coverage of the powertrain, frame, operator's cab, cooling system, drivetrain, brake system, hydraulics, and electrical systems. Additionally, the manual offers valuable information on diagnostic troubleshooting, periodic maintenance, capacities, specifications, and reference materials such as diagrams and schematics, ensuring that owners and technicians have the resources needed for effective upkeep and repair.
Original Illustrated Factory Workshop Service Manual for Yale Diesel/LPG Forklift Truck F813 Series.
Original factory manuals for Yale Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck. All Manuals Printable and contains Searchable Text
Covered models:
GDP080VX
GDP090VX
GDP100VX
GDP110VX
GDP120VX
GLP080VX
GLP090VX
GLP100VX
GLP110VX
GLP120VX
GP080VX
GP090VX
GP100VX
GP110VX
GP120VX
Language: English
Compatible WIN/Mac
Format: ZIP, Contained Set of PDF Manuals
Contents:
POWERTRAIN
FRAME
OPERATOR'S CAB
COOLING SYSTEM
POWERTRAIN
B4.5RGT - SHOP MANUAL (OVERHAUL) 1991 =>
GM POWERTRAIN
GM 4.3L V-6 ENGINES
LPG FUEL SYSTEM (GM 4.3L)
GASOLINE FUEL SYSTEM (GM 4.3L)
HIGH VOLTAGE SWITCH (HVS) IGNITION
DRIVETRAIN
1 AND 2-SPEED POWERSHIFT TRANSMISSION REPAIR
DRIVE AXLE - DRY BRAKE
Drive Axle and Differential Assembly Repair
BRAKE SYSTEM
HYDRAULICS
STEERING AXLE
HYDRAULIC GEAR PUMP
HYDRAULIC CLEANLINESS PROCEDURES
MAIN CONTROL VALVE
CYLINDER REPAIR
MAST REPAIRS
ELECTRICAL
WIRE HARNESS REPAIR
USER INTERFACE
USER INTERFACE
ELECTRICAL SYSTEM
REFERENCE MATERIAL
METRIC AND INCH (SAE) FASTENERS
CALIBRATION PROCEDURES
DIAGRAMS AND SCHEMATICS
Periodic Maintenance
CAPACITIES AND SPECIFICATIONS
DIAGNOSTIC TROUBLESHOOTING
DIAGNOSTIC TROUBLESHOOTING MANUAL
DIAGNOSTIC TROUBLESHOOTING UPDATES
HIGH ENGINE WATER TEMPERATURE
